Entegra Coach Launch 19Y

All-electric is what the Y means here: the 19Y runs a 48V lithium house system charged by a dedicated second alternator, with no generator, while the 19YG uses an LP generator and AGM batteries. Entegra's Launch is an all-wheel-drive Sprinter 2500 van with a rear lounge, a drop-down overhead bed, hydronic heat and a portable induction cooktop.

Approx. price: —
Length: 19.5 ft
Sleeps: 2

Specifications

Size

Exterior length: 19.5 ft
Exterior height: 10.1 ft
Sleeps: 2
Slide-outs: 0

Tanks and power

Fresh water: 34 gal
Gray water: 19 gal
Black water: 5.5 gal
Factory solar: 200 W
House battery: 48V 165Ah smart lithium (7.9 kWh) with dedicated 2nd 48V alternator

Chassis

Chassis: Mercedes-Benz Sprinter 2500 AWD, 144 in. wheelbase
Engine: 2.0L I4 twin-turbo diesel, 211 HP / 332 lb-ft
Fuel: Diesel

Standard equipment named by the maker

Mercedes Sprinter 2500 AWD
48V lithium house system 7.9 kWh
3,000W Victron inverter
200W roof solar
Timberline hydronic heating
18,000 BTU Furrion Chill Cube A/C
Portable induction cooktop
Drop-down overhead bed

Weights

2027 maker figures

GVWR: 9,050 lb
Dry weight (UVW): not published
Occupant + cargo (OCCC): not published
Towing capacity: 5,000 lb

What these weights mean →

Size, to scale

051015202530354045 ft

Entegra Coach Launch 19Y · 19.5 ft long · 10′1″ tall

Drawn to one scale from each camper's listed length and, where the maker publishes it, its exterior height. Outlines are typical for the camper type, not traced from this model. The figure is a 6 ft person. The dashed blue line is 25 ft, the length about 93% of national park campgrounds accept.
