Line photo: Winnebago publishes one photo for the Adventurer line, so it may show another floorplan. Windows and slides can differ from the 35F described here.

Winnebago · Class A · 2027

Winnebago Adventurer 35F

Families get a full bath plus a half bath in this upper-tier gas Class A, which sits above the Vista and Sunstar on Ford's F-53. In-floor ducted heat, an electric fireplace, two A/Cs and Winnebago's driver-assist package are standard, while solar is prep only. Around $258,000.

Approx. price: ~$257,575; maker starting price
Length: 35.8 ft
Sleeps: 5

Specifications

Size

Exterior length: 35.8 ft
Exterior height: 12.1 ft
Sleeps: 5

Tanks and power

Fresh water: 74 gal
Gray water: 51 gal
Black water: 63 gal
Factory solar: None
House battery: 4x Group 31 deep-cycle
Generator: 5,500-watt gas w/ automatic start

Chassis

Chassis: Ford F-53
Engine: 7.3L V8 gas, TorqShift 6-speed
Fuel: Gas

Standard equipment named by the maker

Full bath plus half bath
2,000-watt pure-sine inverter/charger
Front 15,000 BTU A/C w/heat pump + rear 13,500 BTU
40,000 BTU in-floor ducted furnace
Automatic hydraulic leveling jacks
Driver Confidence Package (adaptive cruise, lane keeping)
Electric fireplace; washer/dryer prep

Weights

2027 maker figures

GVWR: 22,000 lb
Dry weight (UVW): not published
Occupant + cargo (OCCC): not published
Towing capacity: 4,000 lb

What these weights mean →

Size, to scale

051015202530354045 ft

Winnebago Adventurer 35F · 35.8 ft long · 12′1″ tall

Drawn to one scale from each camper's listed length and, where the maker publishes it, its exterior height. Outlines are typical for the camper type, not traced from this model. The figure is a 6 ft person. The dashed blue line is 25 ft, the length about 93% of national park campgrounds accept.
