Airstream · Travel Trailer · 2027
Airstream Caravel 22FB
Step up from the Bambi to the Caravel and the galley gains a three-burner stove with an oven, along with a 2,000 W inverter and ducted air conditioning. The 22FB is a front-bed plan for up to four people, and its GVWR matches the Bambi 20FB despite the longer body.
- Approx. price
- ~$102,900
- maker starting price
- Length
- 22.2 ft
- Sleeps
- 4
Floorplan

Airstream’s drawing of the 22FB layout. Tap it for the full-size file.
Specifications
Size
- Exterior length
- 22.2 ft
- Exterior height
- 9.4 ft
- Sleeps
- 4
- Slide-outs
- 0
Tanks and power
- Fresh water
- 23 gal
- Gray water
- 30 gal
- Black water
- 17 gal
- Factory solar
- 200 W
- House battery
- 2.5 kWh Deep Cycle Lithium Batteries with Built in Heater
Standard equipment named by the maker
- Heating Source: 18,000 BTU Ducted Furnace
- Air Conditioner - Primary: 13,500 BTU 30 A Service Single Ducted A/C with Heat Pump
- Inverter: 2,000 W
- Cooktop: 3-Burner LP Gas Stove and Oven
- Refrigerator with Freezer: 4.1 cu ft (12 V)
- Water Heating Source: Tankless On Demand LP Water Heater
- Converter: Multi-Stage 50 A Converter
- Enclosed aluminum insulated heated underbelly
What owners report
Drawn from 7 owners' accounts of the Airstream Caravel, mostly 2019–2024 units. It covers the whole Airstream Caravel line, not only this floorplan. Nobody here has camped in it; this is what people who bought one say.
Two owners found factory shortcuts once they looked closely. On a 2019, water dripped from the rear fan after heavy rain because the sealant had never bonded to it, leaving the owner worried about moisture between the skins. On a 2022 16RB, the inverter under the bed was sitting loose on top of the wiring, not fastened to anything, until the owner made aluminum brackets for it.
On the road owners are happier. A 16RB owner who started with an Audi Q5 found it overmatched on curving grades and moved to an F-150, and says the Equalizer hitch makes the trailer feel nearly bulletproof in crosswinds, on ice and in a sudden swerve. A 22FB has crossed most of the US behind a Tesla Model X, and a 20FB went behind a 2.3-litre Ranger, short of power in the hills but workable with an anti-sway hitch. Two owners of the 22-foot models love theirs, and one calls it a one- or two-person trailer despite the sleeps-four rating. Another owner says the outside bin holds only hoses, cords and a few tools, so their generator rides in the truck bed.
What owners like
- +Matched to a capable tow vehicle it stays composed: one owner has crossed most of the US behind a Model X, and another says an F-150 with an Equalizer hitch handles ice, crosswinds and a sudden swerve without drama.
- +Owners of the 22-foot models love the size for one or two people, with a full shower rather than the wet bath of the 16-foot units.
Common complaints
- −Factory workmanship slips in places owners only find later, such as fan sealant that never bonded and an inverter left loose on the wiring.
- −Smaller tow vehicles run out of breath, with an Audi Q5 overmatched on curvy grades and a 2.3-litre Ranger short of power in the hills.
Weights
2027 maker figures
- Dry weight (UVW)
- 4,175 lb
- GVWR
- 5,000 lb
- Hitch weight, dry
- 525 lb
- Cargo capacity (CCC)
- 825 lb
825 lb between brochure dry weight and GVWR. Water (8.3 lb a gallon), food, gear, propane and dealer-added options all come out of it.
What can tow it? A tow vehicle rated to pull at least 5,000 lb. That is the Airstream Caravel 22FB’s GVWR, the most it may weigh loaded, and the number to hold against a tow rating instead of the dry weight. Loaded to that weight it puts roughly 500 lb to 750 lb on the hitch ball (10 to 15 percent; the maker lists 525 lb dry), which comes out of the tow vehicle’s payload along with passengers and cargo. At 7,000 lb or less it is on our list of trailers a half-ton truck can pull.
Size, to scale
- Airstream Caravel 22FB · 22.2 ft long · 9′5″ tall
Compared with
Similar models

Travel Trailer · Airstream
Airstream Flying Cloud 23FB
- Length
- 23.9 ft
- Sleeps
- 4
- GVWR
- 6,000 lb
- 300 W solar
- 37 gal fresh
~$115,900
24 owner accounts →

Travel Trailer · Airstream
Airstream Bambi 20FB
- Length
- 20.6 ft
- Sleeps
- 4
- GVWR
- 5,000 lb
- 200 W solar
- 23 gal fresh
~$82,400
29 owner accounts →

Travel Trailer · Airstream
Airstream Flying Cloud 25FB
- Length
- 26.2 ft
- Sleeps
- 6
- GVWR
- 7,300 lb
- 300 W solar
- 39 gal fresh
~$128,400
24 owner accounts →

Travel Trailer · Airstream
Airstream Bambi 16RB
- Length
- 16.2 ft
- Sleeps
- 4
- GVWR
- 3,500 lb
- 100 W solar
- 23 gal fresh
~$75,400
29 owner accounts →
Where these figures come from
Taken from these pages. Options and later model-year changes can move any of them.
