Line photo: Winnebago publishes one photo for the EKKO Sprinter line, so it may show another floorplan. Windows and slides can differ from the 23B described here.

Winnebago · Class C · 2027

Winnebago EKKO Sprinter 23B

Diesel and five seats separate this Sprinter EKKO from the Transit-based 22A. The four-mode lounge, optional pop-top, cassette-toilet dry/wet bath and heated holding compartment carry over, and it adds an LP generator and more roof solar. Around $250,000.

Approx. price: ~$250,014; maker starting price
Length: 24.5 ft
Sleeps: 5

Specifications

Size

Exterior length: 24.5 ft
Exterior height: 10.9 ft
Sleeps: 5
Slide-outs: 0

Tanks and power

Fresh water: 50 gal
Gray water: 51 gal
Factory solar: 530 W
House battery: 1x 320Ah Lithionics lithium (standard)
Generator: 2,500-watt LP (standard, deletable)

Chassis

Chassis: Mercedes-Benz Sprinter
Engine: 2.0L turbo-diesel 4-cyl, 9-speed
Fuel: Diesel

Standard equipment named by the maker

Mercedes Sprinter chassis, turbo-diesel
Multifunction lounge with 4 modes; optional pop-top (sleeps 5)
Dry/wet bath, 5-gal cassette toilet
530 W solar (2x215 + 1x100) without pop-top
2,000 W inverter, second alternator
Truma VarioHeat + AquaGo tankless
Heated holding tank compartment

Weights

2027 maker figures

GVWR: 11,030 lb
Dry weight (UVW): not published
Occupant + cargo (OCCC): not published
Towing capacity: 4,220 lb

What these weights mean →

Size, to scale

051015202530354045 ft

Winnebago EKKO Sprinter 23B · 24.5 ft long · 10′11″ tall

Drawn to one scale from each camper's listed length and, where the maker publishes it, its exterior height. Outlines are typical for the camper type, not traced from this model. The figure is a 6 ft person. The dashed blue line is 25 ft, the length about 93% of national park campgrounds accept.
