Brinkley Model G 3950

Brinkley's flagship toy-hauler layout pairs open living with a 14-foot garage whose bath walls fold away to turn it into flex space. It rides on triple axles with 800 W of solar, a lithium battery and a dual-fuel generator fed by the onboard fuel station, and its GVWR calls for a heavy-duty truck. Dealers list it sleeping nine across three slides.

Approx. price: ~$229,898; maker MSRP
Length: 45.42 ft
Sleeps: 9

Specifications

Size

Exterior length: 45.42 ft
Exterior height: 13.33 ft
Sleeps: 9
Slide-outs: 3

Tanks and power

Fresh water: 150 gal
Gray water: 156 gal
Black water: 85 gal
Factory solar: 800 W
House battery: 200Ah self-heating lithium (standard)
Generator: FlexPower 5500 EFI dual-fuel (gas/LP) inverter generator (standard)

Standard equipment named by the maker

14ft garage/flex space with fold-away bath walls
Triple axle on 17.5in H-rated 16-ply tires
800W roof solar (4x 200W) with Victron 50A MPPT controller
60-gallon fuel station (2x 30) feeding generator and fuel pump
Low-pitch 100in ramp door rated 3,000 lb, 1,500 lb patio rating
79.5in bedroom and bath ceilings
101in wide body

Weights

2027 maker figures

Dry weight (UVW): 18,900 lb
GVWR: 23,000 lb
Pin weight, dry: 3,450 lb
Cargo capacity (CCC): not published

4,100 lb between brochure dry weight and GVWR. Water (8.3 lb a gallon), food, gear, propane and dealer-added options all come out of it.

What these weights mean →

Size, to scale

051015202530354045 ft

Brinkley Model G 3950 · 45.42 ft long · 13′4″ tall

Drawn to one scale from each camper's listed length and, where the maker publishes it, its exterior height. Outlines are typical for the camper type, not traced from this model. The figure is a 6 ft person. The dashed blue line is 25 ft, the length about 93% of national park campgrounds accept.
